White position light: 3W

Amber position light: 3W

Warning light: 2,5W

Voltage (V DC): 10-32V DC

Consumption (W): 8,5

Patterns: 21

Functions: Front position white, Amber position light, Warning light middle part

Connection: Cable

Cable length (mm): 1000

Color housing: Black

Color lens: Dark tinted

Color LED´s: White and Amber

Material housing/chassi: Polycarbonate

Material lens: Polycarbonate

Length (mm): 125

Depth (mm): 32

Height (mm): 52

CC (mm): 109

IP-class: 69K

Operating temperature:-30 - +60°C

ADR-approved: No

According to regulation: ECE R148 (R7,R91)

EMC: ECE R10
